Sensitive area

A

1

mm²

Absorber area

Thermopile resistance

R_TP

75±20

KΩ

Responsivity

R

165±40

V/W

500K, with filter cut-on 5.5 um

Time constant

τ

15

ms

Noise voltage

V_N

35.2

nV/Hz^1/2

25ºC

Specific detectivity

D*

1.65*10⁸

cmHz^1/2/W

25ºC

TC of resistance

TC_RTP

0.08±0.04

%/K

-40ºC ~100ºC ambient

Field of view

Fov

20

Degrees

At 50% intensity points

Thermistor resistance

100±3

KΩ

25ºC

β-value

3950±20

K

Defined at 25ºC/50ºC
